PlB self-amalgamating Tape

Code: XF-SCP
Color: Black

XF-SCP High-voltage rubber insulation tape is a kind of high-pressure self-adhesive polyisobutylene rubber insulation tape with good electrical insulation performance, UV resistance, chemical corrosion resistance, and temperature resistance.

CONTACT NOW PDF DOWNLOAD

Details

Tags

PRODUCT APPLICATION

Main insulation restoration of 600v-69kv solid dielectric cable: When a stress cone is made on solid dielectric cable up to 69kV, it is the main insulation; Jacket restoration of intermediate joint and terminal; Moisture-proof seals for electrical connections:Businsulation: Cable end seal. When wrapping, stretch the tape so that it is 3/4 of the width before stretching. Wrapped PVC electrical tape outside to provide mechanical protection.

PRODUCT Technical indicators

SPECIFICATIONS： XF-SCP
PROPERTY	VALUE	UNIT	TEST METHOD
Physical property
Thickness	0.50	mm	ASTM-D-4325
Tensile Strength	350	psi	ASTM-D-4325
Elongation at break	700	%	ASTM-D-4325
Rated operating temperature	90	℃	ASTM-D-4325
Emergency Overload Temperature	130	℃	ASTM-D-4325
Water Absorption	0.84	%	ASTM-D-570
Ozone resistance	PASS	---	ASTM-D-4325
UV resistance	PASS	---	ASTM-D-4325
Electrical property
Dielectric Strength	36	kV/mm	ASTM-D-4325
Dielectric Constant
-24h@23℃	2.6	---	ASTM-D-4325
168h@70℃	2.6	---	ASTM-D-4325
DielectricFactor
-96h50℃50%RH	10	Ohm-cm	ASTM-D-4325
-96h96℃50%RH	15	Ohm-cm	ASTM-D-4325
Volume Resistivity
-96h23℃50%RH	1016	Ohm-cm	ASTM-D-4325
-96h23℃50%RH	1016	Ohm-cm	ASTM-D-4325
Data in the table represent average test results and are not to be used for specification purposes. The product user should make his l her own tests to determine the product.it's suitable for the intended use.
