Self-fusing Silicone Rubber Tape

Code: XF-GXJ
Color: Black Red White Green Blue Yellow Grey XF-GXJ Self-fusing silicone rubber tape is made of high-temperature sticky inorganic silicone rubber which can be connected with adhesive tape, The adhesive tape is attached with a protective layer that can be easily peeled off. it can be used under the h-grade high temperature250C(365F). It is especially suitable for wrapping in the outermost layer of cable terminal and can resist electric marks.

CONTACT NOW PDF DOWNLOAD

Details

Tags

PRODUCT APPLICATION

Large dosage, superior performance anti-fouling,anti-hydrochloric acid,anti-ultraviolet, waterproof; resistance oxygen, ozone, cold, heat, high pressure, and other characteristics.

PRODUCT Technical indicators

SPECIFICATIONS： XF-GXJ
PROPERTY	VALUE	UNIT	TEST METHOD
Physical property
Total Thickness	0.5	mm	ASTM-D-1000
Tensile Strength	20	N/cm	ASTM-D-1000
Elongation at break	180	%	ASTM-D-1000
180℃ peel strength to steel	1.5	N/cm	ASTM-D-1000
Unwind force	2-6	N/19mm	ASTM-D-1000
Data in the table represent average test results and are not to be used for specification purposes. The product user should make his l her own tests to determine the product.it's suitable for the intended use.

PRODUCT General specifications

STANDARD SIZES:
Width	Length	Thickness
25mm	5m	0.5mm
Other sizes and cores are available. Contact factory

PRODUCT PACKAGE
